Optimax® Strapping Machines
From: £1,035.00
- Optimax® Automatic and Semi-Automatic Strapping Machines
- 12-month warranty on all parts
- Automatic Strapping Machines – Stap loads automatically
- Semi-Automatic Machines – Stap is hand fed into the machine
- Machines available from stock
- Videos available to view in the description
- Click “i” button in table for more information (Contents, specifications etc)
More Info
Product Code
Option Name
Price per Unit
Price
Quantity
TMS300
TMS300
Semi Automatic - 6mm-16mm Polyprop Strapping
£1,035.00
Optimax® Strapping Machines
Semi Automatic - 6mm-16mm Polyprop Strapping
TMS300Product Features
- Simple use and maintenance.
- Safety interlocked stainless steel top plate.
- Enclosed cabinet.
- Fixed/swivel castors.
- Manual strap tension adjustment.
- Reliable, energy-efficient operation.
- Compatible with 200mm/280mm core strapping.
Specifications:
- Suitable for use with Polypropylene Strapping
- Machine Weight: 100kg
- Machine Dimensions (w x d x h): 920 x 595 x 785mm
- Strap Widths: 6-16mm
- Strap Thickness PP (min/max): 0.5-0.75mm
- Tension: 15-45kg
- Speed/Cycle: 3 secs
- Power Requirement: 240v 50Hz
- Power Consumption: 250w
PLR100
PLR100
Semi Automatic Low Level - 9mm-16mm Polyprop Strapping
£1,472.00
Optimax® Strapping Machines
Semi Automatic Low Level - 9mm-16mm Polyprop Strapping
PLR100Product Features
- 355mm table height.
- Safety interlocked stainless steel top plate.
- Braking swivel castors.
- External strap tension adjustment.
- Reliable, energy efficient operation.
- Simple use and maintenance.
- Compatible with 200mm/280mm core strapping.
Specifications:
- Suitable for use with Polypropylene Strapping
- Machine Weight: 80kg
- Machine Dimensions (w x d x h): 1476 x 582 x 355mm
- Strap Widths: 9-16mm
- Strap Thickness PP (min/max): 0.5-0.75mm
- Tension: 15-45kg
- Speed/Cycle: 3 secs
- Power Requirement: 240v 50Hz
- Power Consumption: 250w
TRS600-9
TRS600-9
Automatic - 9mm Strap - Arch Size 850mm x 600mm
£3,335.42
Optimax® Strapping Machines
Automatic - 9mm Strap - Arch Size 850mm x 600mm
TRS600-9Product Features
- Automatic strap feed.
- Short feed sensor.
- Auto loop ejector.
- Externally mounted coil.
- Entry level arch strapper with excellent build quality.
- Suitable for high volume strapping.
- Minimal downtime and easy coil change.
Specifications:
- Machine Weight: 263kg
- Machine Dimensions (w x d x h): 1430 x 620 x 1540mm
- Arch Size: 850 x 600mm
- Strap Widths: 9mm
- Tension: 10-70kg
- Speed/Cycle: 2.2 secs
- Power Requirement: 230v 50Hz
- Power Consumption: 1.2kW
TRS600-12
TRS600-12
Automatic - 12mm Strap - Arch Size 850mm x 600mm
£3,259.46
Optimax® Strapping Machines
Automatic - 12mm Strap - Arch Size 850mm x 600mm
TRS600-12Product Features
- Automatic strap feed.
- Short feed sensor.
- Auto loop ejector.
- Externally mounted coil.
- Entry level arch strapper with excellent build quality.
- Suitable for high volume strapping.
- Minimal downtime and easy coil change.
Specifications:
- Machine Weight: 220kg
- Machine Dimensions (w x d x h): 1430 x 620 x 1540mm
- Arch Size: 850 x 600mm
- Strap Widths: 12mm
- Thickness: 0.55-0.75mm
- Tension: 10-70kg
- Speed/Cycle: 2.6 secs
- Power Requirement: 240v 50Hz
- Power Consumption: 1.2kW
TRS600-12L
TRS600-12L
Automatic - 12mm Strap - Arch Size 1050mm x 800mm
£3,920.00
Optimax® Strapping Machines
Automatic - 12mm Strap - Arch Size 1050mm x 800mm
TRS600-12LProduct Features
- Automatic strap feed.
- Short feed sensor.
- Auto loop ejector.
- Externally mounted coil.
- Entry level arch strapper with excellent build quality.
- Suitable for high volume strapping.
- Minimal downtime and easy coil change.
Specifications:
- Machine Weight: 280kg
- Machine Dimensions (w x d x h): 1630 x 620 x 1740mm
- Arch Size: 1050 x 800mm
- Strap Widths: 12mm
- Tension: 10-70kg
- Speed/Cycle: 2.2 secs
- Power Requirement: 230v 50Hz
- Power Consumption: 1.2kW
AFS900-9
AFS900-9
Automatic - 9mm Strap - Arch Size 850mm x 600mm
£4,133.00
Optimax® Strapping Machines
Automatic - 9mm Strap - Arch Size 850mm x 600mm
AFS900-9Product Features
- Automatic strap feed for load-and-go reel changes.
- Short-feed sensor to prevent strap misfeed.
- Automatic strap loop ejector for accidental cycle activation.
- Electronic tension control.
- Externally mounted coil.
- One of the most advanced strapping machines in its class.
- Fast tension adjustment.
- Minimal downtime and easy coil change.
Specifications:
- Machine Weight: 263kg
- Machine Dimensions (w x d x h): 1430 x 620 x 1540mm
- Arch Size: 850 x 600mm
- Strap Widths: 9mm
- Tension: 10-70kg
- Speed/Cycle: 2.6 secs
- Power Requirement: 230v 50Hz
- Power Consumption: 1.2kW
AFS90012
AFS90012
Automatic - 12mm Strap - Arch Size 850mm x 600mm
£4,095.00
Optimax® Strapping Machines
Automatic - 12mm Strap - Arch Size 850mm x 600mm
AFS90012Product Features
- Automatic strap feed for load-and-go reel changes.
- Short-feed sensor to prevent strap misfeed.
- Automatic strap loop ejector for accidental cycle activation.
- Electronic tension control.
- Externally mounted coil.
- One of the most advanced strapping machines in its class.
- Fast tension adjustment.
- Minimal downtime and easy coil change.
Specifications:
- Machine Weight: 263kg
- Machine Dimensions (w x d x h): 1430 x 620 x 1540mm
- Arch Size: 850 x 600mm
- Strap Widths: 12mm
- Tension: 10-70kg
- Speed/Cycle: 2.6 secs
- Power Requirement: 230v 50Hz
- Power Consumption: 1.2kW
AFS900-12L
AFS900-12L
Automatic -12mm Strap - Arch Size 1050mm x 800mm
£4,695.00
Optimax® Strapping Machines
Automatic -12mm Strap - Arch Size 1050mm x 800mm
AFS900-12LProduct Features
- Automatic strap feed for load-and-go reel changes.
- Short-feed sensor to prevent strap misfeed.
- Automatic strap loop ejector for accidental cycle activation.
- Electronic tension control.
- Externally mounted coil.
- One of the most advanced strapping machines in its class.
- Fast tension adjustment.
- Minimal downtime and easy coil change.
Specifications:
- Suitable for use with Polypropylene Strapping
- Machine Weight: 280kg
- Machine Dimensions (w x d x h): 1630 x 620 x 1740mm
- Arch Size: 1050 x 800mm
- Strap Widths: 12mm
- Tension: 10-70kg
- Speed/Cycle: 2.6 secs
- Power Requirement: 230v 50Hz
- Power Consumption: 1.2kW
Description
Strapping Machines
- Optimax® Strapping Machines are a worthwhile investment to improve the efficiency of your business.
- Strapping Machines eliminate the use of Strapping Tensioners, Sealers, Combination Tools and Seals and Buckles, as the complete process can be conducted by our Automatic and Semi-Automatic Strapping Machines.
- All our Strapping Machines are backed by our 12-month parts or return to base warranty as standard.
Optimax® Semi-Automatic Strapping Machine
- Perfect upgrade from a hand strapping operation when you have an increase of items to strap.
- These machines are a good starter level as they will tension and seal the polypropylene strapping.
- All the operator needs to do is feed the strap around the parcel, push the button and the machine will automatically tension the strapping and cut and seal all in one motion.
Optimax® Automatic Strapping Machine
- These are level up from the Semi-Automatic Strapping Machines and are for a high output of goods.
- Quicker and simpler than the Semi-Automatic machines.
- Simply place the parcel under the machine and activate the machine. It will then tension, seal, and cut the strap, leaving the machine ready for the next parcel.
Optimax® Vertical Pallet Strapping Machine
- Lightweight and compact for manoeuvrability.
- Compact mechanical strapping head and extremely low noise sealing head.
- 30% fewer moving parts substantially reduces maintenance issues.
- Adjustable weld cooling time.
- Jog switch sets the machine to exactly the correct position for maintenance.
Optimax® Semi Automatic Side Seal Strapping Machine
- Stainless steel construction.
- Braking swivel castors.
- External strap tension adjustment.
- Reliable, energy efficient operation.
- Simple use and maintenance.
Videos
TMS300 – Semi Automatic Strapping Machine
TRS600 – Automatic Strapping Machine
AFS900 – Automatic Strapping Machine
